ACT-700T UHF Miniature Bodypack Transmitter

ACT-700T UHF Miniature Bodypack Transmitter The new MIPRO ACT-700T UHF bodypack transmitter is the latest in a line of premium, innovative and reliable wireless products from MIPRO. The ACT-700T is enclosed in a rugged magnesium alloy housing. The redesigned patented battery compartment accommodates two alkaline batteries or one rechargeable 18500 lithium battery, a USB Type-C charging port with included cable provides for safe and intelligent charging. The new ACT-700T is supplied with the MU-55LX omnidirectional lavaliere microphone and features improved RF circuitry, low power consumption characteristics, a multifunction backlit LCD, direct and remote mute control, selectable input impedance, selectable RF output and has a menu lockout feature. With 72 MHz of bandwidth, the ACT-700T accommodates up to 2881 UHF frequencies. The new MIPRO ACT-700T is innovative, reliable and offers the premium performance and flexibility required for today’s professional audio applications.

  • MU55LX Lavaliere included
  • Magnesium alloy housing
  • Multifunction backlit LCD
  • AF metering
  • 13 hours ‐ 1 ICR 18500 rechargeable battery or 2 AA alkaline batteries
  • USB Type‐C charging port
  • Direct and remote mute control
  • Selectable input impedance
  • Selectable RF output
  • Selectable mute functionality
  • Menu lockout feature

  • Frequency Bands 5UA: 482~554 MHz5NU: 554~604 MHz
  • RF Power Output 10mW/50mW (switchable)
  • Deviation Range <± 40 kHz
  • Spurious Emission <4 mW
  • Oscillation Mode PLL Synthesized
  • Frequency Stability ≦±0.005% (-10~+60℃)
  • Modulation Type Analog
  • Max Audio Input 0 dBV
  • Battery 1 ICR 18500 rechargeable lithium battery OR 2 AA alkaline batteries
  • Battery Life 13 hours
  • Dimensions 63(W)×82(H)×22(D)mm / 2.5(W)×3.2(H)×0.9(D)"
  • Weight Approx. 87g / 3oz, excluding batteries
