MIPRO’s Digital Diversity ACT-2400 Series wireless system addresses the industry’s 2.4GHz issues of range, signal stability and channel density. The ACT-2414A receivers operate in the 2.4GHz-ISM band using stable 4- frequency FSK modulation circuitry to provide strong RF signal stability and extended range, utilize dual-tuner true digital diversity reception, and deliver 12 compatible channel operations without signal dropout.
The ACT-2414A receiver features removable antennas and includes rack ears. These receivers utilize the
ACT-24HC,
ACT-24TC and
MT-24 transmitters.
- MIPRO’s Digital Diversity ACT-2400 Series wireless system addresses the industry’s 2.4GHz issues of range, signal stability and channel density
- By using an adaptive tracking algorithm, the 2400-Series skips the common Wi-Fi frequencies effectively avoiding interference from most 2.4GHz communication products
- Utilizes a 4 frequency hopping spread spectrum technique that avoids and remaining interference
- With dual tuner true digital diversity receiving, receiving distance is up to 100 meters (330 ft.) with no signal drop-out
- 12 compatible simultaneous channel operation
- 24-bit / 44.1 kHz digital audio sampling
- Lo-Cut and Flat EQ settings
- Adjustable AF gain & RF power output
- Full-rack dual and quad channel systems
- Receiver is enclosed in a sturdy metal case
- Removable antennas
- Rack mount hardware included
- Chassis: EIA Standard 19" 1U
- Display Graphic: OLED
- Frequency Range: 2.4GHz ISM band (2.4 – 2.4835GHz)
- Preset Frequency: 12
- Frequency-hopping: Each channel has 4 preset hopping frequencies
- Receiving Mode: Dual-tuner Digital Diversity
- Audio Sampling: 24-bit / 44.1 kHz
- Sensitivity: -95 dBm
- S/N Ratio: > 115 dB(A)
- T.H.D.: 0.1 % @ 1 kHz
- Audio Frequency Response: 20 Hz – 20 kHz (-2 dB)
- Output Connectors: Balanced XLR & Unbalanced 6.3 mm (1/4 ")
- Audio Output Adjustment: 0 dB (standard), -10 – +20 dB adjustable range
- Latency: < 4.0 ms
- Antenna: Rear panel, detachable
- Power Supply: External AC Power Supply
- Power Consumption: 2.4 W
- Dimensions: 420 × 44 × 180 mm / 16.5 × 1.7 × 7.1 "
- Weight: Approx. 1.6 kg / 3.5 lbs
- Operating Temperature: -10 – +60℃
