Receiver: MIPRO’s Digital Diversity ACT-2400 Series wireless system addresses the industry’s 2.4GHz issues of range, signal stability and channel density. By using an adaptive tracking algorithm, the 2400-Series skips the common Wi-Fi frequencies effectively avoiding interference from most 2.4GHz communication products. Utilizes a 4 frequency hopping spread spectrum technique that avoids any remaining interference. With dual tuner true digital diversity receiving, receiving distance is up to 100 meters (330 ft.) with no signal drop-out. 12 compatible simultaneous channel operation. 24-bit / 44.1 kHz digital audio sampling. Lo-Cut and Flat EQ settings. Adjustable AF gain & RF power output. Half rack single and dual channel systems. Receiver is enclosed in a sturdy metal case. Front mounted antennas. Optional rack mount hardware. Transmitter: Easy to use and the plug can be rotated up to 90°. Operates in 2.4 GHz user license-free ISM band. True diversity technology and stable digital FSK modulation circuit eliminate signal dropouts and ensure best reception quality. Combining FHSS frequency-hopping technique with adaptive tracking algorithm to prevent interferences from other 2.4 GHz wireless devices. Eliminates the annoying compander noise that exists in analog systems. Transmitter has high-efficiency circuitry design. The included single rechargeable lithium battery can be easily removed or interchanged for charging. The intelligent battery charger maintains a high charge capacity for up to 600 charge cycles for cost saving and is environmentally friendly. Easily replaceable battery or recharge the GT-24 directly with an adaptor plug.

Receiver: Chassis: EIA Standard 19″ 1/2U. Display Graphic: OLED. Frequency Range: 2.4GHz ISM band (2.4 – 2.4835GHz). Preset Frequency: 12. Frequency-hopping: Each channel has 4 preset hopping frequencies. Receiving Mode: Dual-tuner Digital Diversity. Audio Sampling: 24-bit / 44.1 kHz. Sensitivity: -95 dBm. S/N Ratio: > 115 dB(A). T.H.D.: 0.1 % @ 1 kHz. Audio Frequency Response: 20 Hz – 20 kHz (-2 dB). Output Connectors: Balanced XLR & Unbalanced 6.3 mm (1/4 “). Audio Output Adjustment: 0 dB (standard), -10 – +20 dB adjustable range. Latency: < 4.0 ms. Antenna: 2 × 50 Ω fixed antenna. Power Supply: External AC Power Supply. Power Consumption: 1.6 W. Dimensions: 210 × 44 × 180 mm / 8.3 × 1.7 × 7.1 “. Weight: Approx. 0.75 kg / 1.7 lbs. Operating Temperature: -10 – +60℃. Transmitter: Frequency Range: 2.4GHz ISM band (2.4 – 2.4835GHz). RF Output Power: 2 mW / 10 mW switchable (country dependent). Transmitting Mode: Frequency hopping. Maximum Audio Input: 6.5 dBV. Audio Sampling: 24-bit / 44.1 kHz Rate. Frequency Response: 20 Hz – 20 kHz. Latency: < 4.0 ms. Battery Meter: 4-level green/red LED display. Impedance: 1.0 M Ω. Connector: 3.5 mm to 6.3 mm threaded adaptor. Battery Type: ICR 18500 rechargeable lithium battery. Current Consumption: 138 mA. Operating Time: A 25-minute quick charge provides up to 1 hour usage. Minimum 10 hours of operation per 4-hour full charge. Dimensions (W × H × D): 84 × 35 × 29 mm / 3.3 × 1.4 × 1.1 “. Net Weight: Approx. 61 g / 2.2 oz, excluding battery.

ACT-2401/MT-24 Single Channel 2.4GHz Guitar System

MIPRO’s Digital Diversity ACT-2400 Series wireless system addresses the industry’s 2.4GHz issues of range, signal stability and channel density. The 1/2U, single- and dual-channel digital receivers operate in the 2.4GHz-ISM band using stable 4- requency FSK modulation circuitry to provide strong RF signal stability and extended range, utilize dual-tuner true digital diversity reception, and deliver 12 compatible channel operations without signal dropout. The MT-24 is a digital transmitter with an integrated 3.5 mm to 6.3 mm threaded adaptor. The plug can be rotated up to 90°. Simply plug it into the guitar for a cable-free, truly wireless audio performance. The MT-24 wireless digital guitar transmitter is for use with MIPRO’s ACT 2400-Series systems. The MT-24 can be plugged into an electric/acoustic guitar, bass, keyboard, accordion, PC, smartphone, projector with phone jack audio output for wireless audio amplification and performance. The ACT-2401/MT-24 system includes one single channel ACT-2401 receiver and MT-24 guitar transmitter.
